Latest Puma AFS Connect and Multicontroller tractors come with significant upgrades

Made in St Valentin, Austria, the new models feature a larger, quieter cab, customisable functions, integral AFS Connect telematics, more power and a bigger footprint.

Cab enhancements at the heart of upgrades

Among the most visible changes on the new Puma AFS Connect tractors is a new cab design. Providing 8% more volume, the cab gives the operator more head and leg room and additional storage.

One of the most significant upgrades is reduced internal noise levels of 66 decibels, among the lowest in the sector, matched by an interior which features a premium automotive-style trim. There is also an additional 11% glass area for enhanced vision and safety, and a windscreen wiper providing up to 240° of coverage.

To match comfort with control, a new Multicontroller armrest on both Multicontroller and CVXDrive models now incorporates more features, with many customisable. These include a turn-and-press encoder dial that can be used if preferred as an alternative to swiping the new 12in AFS Pro 1200 touchscreen for display navigation and feature selection.

Moreover, the terminal allows for CVX transmission and front axle suspension responses to be configured, as well as LED-lit remote valve paddles to be assigned according to preference. Operation of the AFS 1200 is supplemented by hot key quick-access buttons.

Ride quality and comfort is further enhanced by a semi-active hydraulic cab suspension, adjustable to individual preferences or changing terrain.

Meanwhile, the optional Case IH Advanced Vehicle Suspension (AVS) provides further improvement by integrating the semi-active cab suspension, rear hitch and front axle suspension and co-ordinating them via software that reacts instantly to changing surfaces.

Via the AFS Pro 1200 touchscreen terminal, operators can set up and control AccuGuide guidance, make tractor and ISOBUS implement settings, and set up AFS Connect telematics to record and transfer operating data to the MyCaseIH online portal. This allows for remote machine monitoring by owners and, with permission, dealers.

Puma AFS Connect models are also available with Tractor Implement Management (TIM), which extends the ISOBUS links with compatible equipment by allowing the implement to automatically adjust the tractor’s speed and steering according to the workload, such as swath density when working with a baler.

Proven drivelines now with custom possibilities

The new Puma tractors combine a compact 2.88m wheelbase with rated power outputs of 180-220hp (Multicontroller models) and 180-260hp (CVXDrive models), which can be increased to 224-260hp and 224-302hp respectively with Power Management.

Larger tyre options also provide 11% more power, 15% more fuel tank volume, and 18% more contact area.

Puma AFS Connect tractors produce a maximum 1,250Nm torque at 1,500 rpm on the largest model, with up to 11% more power across the range. Engine service interval has been extended to 750 hours.

On CVX models, larger, stronger axles permit a gross vehicle weight of up to 15,000 kg and allow fitment of up to 2.05m rear tyres (710/70 R42), increasing footprint by up to 18% for more traction and flotation.

On 50kph models, top speed is attainable at 1,550 rpm to minimise fuel consumption from the 15% larger fuel tank, which holds 470 litres of diesel and 54 litres of DEF, for up to three hours’ extra work. The new tank moulding incorporates toolbox and stowage space, as well as an integral five-litre hand-washing tank.

In addition, a new combination of added-value telemetry services grouped to encompass all aspects of service support is now available for Case IH Puma tractors. Key features of Safeguard Connect, which complements AFS Connect telemetry, include extended Safeguard warranty, pre-season inspection, dealer remote support, Max Service 24/7 back-up, AFS Connect subscription and full operator training.
